TANK – IMO 0
Tank – containers with level of security “IMО 0” are used to transport non – hazardous food cargo which not require loading/unloading under high pressure: vegetable oils, mineral water, milk, juices (not concentrated). The capacity of such containers is 20- 30 thousand litres. The shell thickness of the cistern – 2 mm. Tank – container can be equipped with a layer of heat isolation and steam curing.
|Capacity||Volume||Wall thickness||Maximum pressure||Working pressure||Steam heating surface||Thermal Insulation|
|20||17000 – 26000||2-3||0.6||0||1.5-5||0,7 – 0,17|
|Tare weight||Maximum gross weight||Maximum load capacity||Type of product||Safety devices according international requirements|
|IMO 0 (Water,Wine,Oil,Milk)||3500||24000 – 30000||20500||Water, Wine, Oil, Milk||valve|
